HVAC Replacement Part | Digital-Non-Programmable | SKU TH5110D1022
Thermostat, Non-Programmable, 1 A, Premier White, 50/60 Hz
Product Description
The Thermostat, Non-Programmable, 1 A, Premier White, 50/60 Hz is an HVAC replacement thermostat. It is used for digital-non-programmable service and replacement work. Key details include 1 A Max, Premier White, 50/60 Hz, 20 to 30 VAC, Backlight LCD, 5 to 90%, Horizontal Mounting, 3 Heat/2 Cool Conventional and Heat Pump System Configuration, 40 to 99 degF, R, RC, C, W (O/B), Y, G Terminal, 4.5 in WD, 3.4375 in HT, 1.3125 in DP.
Document links are included below. Order by part number TH5110D1022 and compare it with the label on your existing component before purchasing.
Technical Specifications - TH5110D1022
| Part Number | TH5110D1022 |
|---|---|
| Full SKU | MHVC-RES-PTST-TH5110D1022 |
| Part Type | Digital-Non-Programmable |
| Category | Thermostats |
| Catalog Detail | 1 A Max, Premier White, 50/60 Hz, 20 to 30 VAC, Backlight LCD, 5 to 90%, Horizontal Mounting, 3 Heat/2 Cool Conventional and Heat Pump System Configuration, 40 to 99 degF, R, RC, C, W (O/B), Y, G Terminal, 4.5 in WD, 3.4375 in HT, 1.3125 in DP |
| Country of Origin | Mexico |
| Unit Height | 3.44 in |
| Unit Width | 4.1875 in |
| Unit Depth | 1.31 in |
| Power Voltage | 20-30 V |
| Unit Weight | 0.5 lb |
| Programmable | No |
| wifi Compatible | No |
Documents & Downloads
