MRCOOL Olympus Duct 24,000 BTU (2 Ton) – DUCT-24HP-230B-O
CLICK HERE TO CONTACT US FOR CUSTOM QUOTES AND QUESTIONS
CLICK TO CALL US 800-543-8933 FOR ANY QUESTIONS
MRCOOL Olympus Duct 24,000 BTU (2 Ton) – DUCT-24HP-230B-O
Overview
The MRCOOL® OLYMPUS 24K DUCT Air Handler offers powerful and efficient heating and cooling for areas up to 1,050 square feet, making it an excellent choice for larger bedrooms, home offices, and compact commercial spaces. Its low-profile ceiling-mounted design allows for a flush installation that blends effortlessly into any space, maintaining a clean and contemporary look. Ideal for both residential and light commercial use, this air handler is engineered for flexibility and style—delivering high performance while preserving valuable floor and wall space. Whether you're outfitting a modern home or a small office, it’s designed to meet your comfort needs without disrupting your room’s layout or design. For convenient operation, the unit includes both a wired wall controller and a handheld remote, offering flexible options for temperature control whether you're working, relaxing, or entertaining. No need to interrupt your day to adjust the settings—just set your ideal climate with ease. Environmentally responsible, the system uses R-454B refrigerant, which offers strong performance with a significantly lower global warming potential. This helps reduce your carbon footprint while keeping energy efficiency and indoor comfort at the forefront. The MRCOOL® OLYMPUS 24K DUCT Air Handler is supported by a limited warranty, 7-year compressor coverage, and a 5-year parts warranty, providing long-term reliability and peace of mind. For those seeking an energy-efficient, discreet, and modern comfort solution, this system delivers performance without compromise.
Quick Facts
- Capacity:24,000 BTU(2 Ton)
- Coverage:Up to 1,050 sq. ft.
- Refrigerant:R-454B
- Voltage/Phase/Frequency:208/230V, 1-Phase, 60 Hz
- Sound:40 / 40 / 37 / 35 / 29.5 dBA(5 speeds)
- Airflow:Ducted
- Fan Speeds:5 (Variable)
- Controls: Wired Wall Controller & Handheld Remote
- Smart/Wi-Fi/App:No
- Listings:UL, CSA, ETL
Use our sizing calculator (BTU Calculator) to dial in the right capacity.
Works With (Outdoor Units)
O-ES-24-HP-C-230C-O1, MULTI4-27HP230C-O, MULTI5-36HP230C-O, MULTI6-48HP230C-O
Included in Your Order
- MRCOOL Olympus 24K Ducted Air Handler– Model:DUCT-24HP-230B-O
- Wired Wall Controller
- Remote Control
- Installation Manual
- Owner’s & Service Information
Lineset, outdoor unit, and accessories sold separately.
Key Features
- Low-profile, ceiling-concealed ducted installation
- Quiet operation down to29.5 dBA
- R-454Blow-GWP refrigerant
- 5 variable fan speeds
- Reusable filter
- Sleep Mode, Auto Cool, Fan-Only option
- UL, CSA, and ETL listed
Technical Specifications
| Specification | Details |
|---|---|
| Brand / Series | MRCOOL / Olympus Duct |
| Model | DUCT-24HP-230B-O |
| GTIN / UPC | 00840255587693 / 840255587693 |
| Unit Type | Mini-Split |
| Tonnage | 2 |
| Voltage / Phase / Cycle | 208/230V / 1-Phase / 60 Hz |
| Max Fuse Breaker | 15 A |
| Min Circuit Ampacity | 3 A |
| Mount Type | Ducted |
| Color | Metal |
| Max Coverage Area | Up to 1,050 sq. ft. |
| Refrigerant Type | R-454B |
| Sound (dBA) | 40 / 40 / 37 / 35 / 29.5 |
| Airflow Direction | Ducted |
| Number of Speeds | 5 (Variable) |
| Oscillation | No |
| Lineset Fitting Type | Flare |
| Liquid / Suction Line | 3/8" / 5/8" |
| Blower Motor Speeds (CFM) | 853.5 / 706.3 / 618 / 500.3 / 500.3 |
| Blower Motor RPM | 950 / 800 / 500 |
| Auxiliary Heater (Included / Available) | No / No |
| Fan Only / Sleep Mode / Auto Cool | Yes / Yes / Yes |
| Wi-Fi / App / iOS / Android | No / No / No / No |
| Remote Included | Yes |
| UL / CSA / ETL Listed | Yes / Yes / Yes |
| Prop 65 | Yes |
| Restricted States | GU, PR, VI |
| Net Dimensions (HxWxD) | 9.65" × 39.37" × 29.53" |
| Net / Gross Weight | 80.47 lbs / 91.93 lbs |
Warranty Information
- Limited(see MRCOOL terms)
- 7-YearCompressor Coverage
- 5-YearParts Warranty
- Registered Labor Warranty: None
- Base Labor Warranty: None
Manuals & Downloads
- Olympus Series Brochure
- Olympus Duct Installation Manual
- Olympus Duct Wiring/Terminal Manual
- Olympus Duct 24K Service Manual
Please note:Indoor air handler must be matched with a compatible MRCOOL outdoor unit. Lineset, controls, and accessories sold separately.
