MRCOOL 3 Ton VersaPro® Central Ducted Heat Pump Condenser | R-454B – MVP-36-HP-C-230A00-O
Summary
The 3 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser (Model MVP-36-HP-C-230A00-O) provides reliable, cost-effective heating and cooling with variable-speed performance. Its compact side-discharge design and DC inverter deliver smooth, quiet operation and energy savings. Pairs with the VersaPro® Central Ducted Air Handler and includes a MRCOOL® Smart Thermostat. Uses eco-forward R-454B refrigerant.
Important
R-454B refrigerant. Variable-speed inverter. Side-discharge, compact footprint. Smart thermostat included.
What's Included
- Outdoor Condenser (MVP-36-HP-C-230A00-O)
- MRCOOL® Smart Thermostat
- Installation & Owner’s Manual
- Service Manual
- Warranty Information
Features
- SEER2 16.1 / EER2 10; HSPF4 8.7 / HSPF5 7.0
- R-454B refrigerant with inverter efficiency
- Quiet operation (~63 dBA), side-discharge
- Durable painted galvanized steel cabinet
- Built-in self-diagnostics
Technical Specifications
| Brand / Series | MRCOOL / VersaPro® Central Ducted Condenser |
| Model | MVP-36-HP-C-230A00-O |
| GTIN | 00840255582711 |
| UPC | 840255582711 |
| Unit Type | Split System Heat Pump |
| Equipment Type | Condenser |
| SEER2 | 16.1 |
| EER2 | 10 |
| HSPF-4 | 8.7 |
| HSPF-5 | 7.0 |
| CFM (Outdoor Airflow) | 2413.2 |
| Tonnage | 3 |
| Cooling Capacity (BTU) | 36,000 |
| Heating Capacity (BTU) | 36,000 |
| Voltage / Phase / Cycle | 208–230 V / 1-Phase / 60 Hz |
| Max Fuse / Breaker (A) | 30 |
| Min Circuit Ampacity (A) | 24 |
| Color | Gray |
| Refrigerant | R-454B |
| Factory Charge (oz) | 116.4 |
| Decibel Rating (dBA) | ~63 |
| Liquid / Suction Line Sizes | 3/8" / 3/4" |
| Wi-Fi / App Compatibility | Yes / Yes (Smart Thermostat included) |
| Certifications | ETL Certified; AHRI Certified; ENERGY STAR®: Yes |
| Net Dimensions (W × D × H) | 37.24" × 16.14" × 31.89" |
| Net / Gross Weight | 153.22 lbs / 163.58 lbs |
| Gross Dimensions (W × D × H) | 42.91" × 19.68" × 34.84" |
| Contains Electronics / Chemicals / Compressed Gas | Yes / Yes / Yes |
Airflow, Refrigerant & Installation Limits
| Outdoor Airflow | 2413.2 CFM |
| Line Set Sizes | Liquid 3/8" • Suction 3/4" |
| Line Length & Elevation | See Installation/Service Manual for rated & max lengths and elevation limits. |
| Additional Refrigerant | See manual for charge adjustment per added line length. |
Compatibility & Pairing
| Works With | VersaPro® Central Ducted Air Handler (matching capacity) |
Warranty Information
- Base Parts Warranty: 10 Years (limited)
- Base Compressor Warranty: 10 Years (limited)
Manuals & Downloads
- Brochure (Gen 2)
- Installation & Owner’s Manual
- Performance Specs
- Condenser Service Manual
- Heat Kit Manual (optional accessory)
Safety & Install Notes
- Install on a solid, level base; follow clearances and anchoring guidance.
- Dedicated 208/230V, 1-phase circuit; include proper disconnect and follow wiring/torque specifications.
- Use specified line sizes; evacuate, leak-check, and charge per R-454B procedures.
- Comply with national/local codes; qualified personnel only.
Environmental & Efficiency Features
R-454B refrigerant and inverter technology support efficient operation and reduced environmental impact.
