Goodman

Goodman 3.5 Ton 14.3 SEER2 Central Air Conditioner Condenser - R32 Single Stage

SKU: GLXS4BA4210

System highlights
AC Type
Air Conditioner Condenser Units
Refrigerant Type
R32
Brand
Goodman
Outdoor Unit
42000 BTU VO (3.5 TON)
Voltage
208-230V
Looking For
Air Conditioner Condenser Units
SEER2 Rating
14.3
Region Approved
Northern States, Southern States

Price

$2,576.00
Shipping calculated at checkout.
Quantity
View full details
Goodman
Goodman 3.5 Ton 14.3 SEER2 Central Air Conditioner Condenser - R32 Single Stage

Product Overview

OVERVIEW

The Goodman brand has been focused on providing efficiency and comfort where it matters most while still being an inexpensive brand. With its superior components and a standard efficiency, the Goodman GLXS4BA4210 air conditioner condenser is a popular choice for homeowners around the United States.

QUICK FACTS

  • Ideal size to cover a medium house in ideal climates
  • 3.5 ton, 14.3 SEER2 AC-only condenser
  • R32: Complies with Clean Air Act New Refrigerant Requirements
  • Fully charged for up to 15' of line set
  • Low sound output
  • Factory-installed filter drier

3.5 Ton

The GLXS4BA4210 Goodman condenser is a 3.5 ton unit, meaning that it can cover up to a small home in an ideal climate. In some unit bundles, the required AC coil may be larger than this condenser in tonnage. This is intentional, as it maintains the unit's efficiency.

14.3 SEER2

The GLXS4BA4210 AC-only conditioner can be up to 14.3 SEER2 in efficiency when paired with the proper equipment. As the standard efficiency on the market for all states, this unit is average in efficiency. Every SEER2 point is 5-7% more efficient than the one lower than it, saving you money the higher the SEER2 rating of the unit. Please note that this product is regulated by DOE Efficiency Standards.

Warranty

The GLXS4BA4210 condenser comes with Goodman's standard 10 year parts warranty with online registration through the manufacturer. An installation that follows your state and local codes is required for the warranty to be upheld.

Durability and Reliability

The GLXS4BA4210 Goodman AC condenser cabinet has a baked-on painted finish and is made of a galvanized-steel, making it approved for up to 500 hours of salt-spray and compliant with the 2010 Florida building code integrity requirements for hurricane-type winds when properly anchored. Moreover, the unit is equipped from the factory with a filter dryer that lowers general wear-and-tear on the unit. The GLXS4BA4210 provides peace of mind thanks to its durability and reliability enhancements.

Installation and Maintenance

The Goodman GLXS4BA4210 AC condenser comes standard with service valves that have sweat connections and easy-access gauge ports, both providing a lower installation difficulty and time to lower installation costs. The outer casing has both a top and a side access to allow for easier maintenance and warranty access when necessary.

Comfort in Mind

The Goodman brand always has its customer's comfort in mind. The GLXS4BA4210 is no exception, with not only using high-quality components but also providing enhanced sound-dampening features that allows the brand to manufacture some of the lowest sound output levels in the industry.

Disclaimer: This condenser contains R-32 refrigerant, classified as an A2L refrigerant, and requires a refrigerant leakage detection system to be installed. To comply with safety standards, this unit must be paired with an R-32 air handler or evaporator coil already equipped with a leakage detection system. Failure to comply with these requirements may result in safety hazards and could void the warranty.

Product Features

  • Energy-Efficienct Compressor
  • Fully charged for 15' of tubing length
  • Copper tube/ enhanced aluminum fin coil-5mm diameter
  • Factory-installed filter drier
  • Sweat connection service valves with easy access to gauge ports
  • Enclosed contactor with lug connection
  • High-pressure switch
  • Capacitors with extended life
  • AHRI Certified
  • ETL Listed

Cabinet Features

  • Removable grille-style top designcompliant with UL 60335-2-40
  • Venturi for increased velocity of airflow
  • Attractive Architectural Gray powder-paintfinish with 500-hour salt-spray approval
  • Wire fan discharge grille
  • Steel louver coil guard
  • Top and side maintenance access
  • Single-panel access to controls with space provided for field-installed accessories
  • When properly anchored, meets the 2023 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)

Technical Specifications - GLXS4BA4210

sku GLXS4BA4210
manufacturer Goodman
product category Unitary
product class Split Air Conditioner
system family Unitary Split System
function category Cooling Only
product type Equipment
unit type Outdoor
market type Residential-Single Family
product family GLXS4B
series name GLXS4B
short description Goodman Split Air Conditioner 14.3 SEER2, Single Stage
family description Energy-Efficient Classic R-32 Split System Air Conditioner, 14.3 SEER2, 1½ To 5 Tons
product description 14.3 SEER2 R-32 AC, 3.5T
cooling btu 40,000
seer2 14.3
decibel level (dba) 72 dBA
refrigerant R-32
compressor type Scroll
liquid line 3/8 in
suction line 7/8 in
electrical 208/240 V | 60 Hz | 1 Ph
max breaker size 30 A
min. breaker size 18.95 A
tonnage 3.5
btu/tonnage 40,000 BTU/3.5 Ton
min/max outdoor temp for cooling 55 °F to 125 °F
height 35.75 in
width 35-1/2 in
depth 35.5 in
weight 72 lb
warranty ALL PARTS - 10 YEARS PARTS
safety information Proposition 65 Label: Yes
product class pim Split Air Conditioner
model efficiency 14.3 SEER2
communication feature No
communication feature type Non-Communicating
export control classification number eccn EAR99
universal product code upc 663051691667
item stocking unit of measure uom EA
pallet qty 1
country of origin USA
us hts code 8415.90.8085
canadian hts code 8415.90.90.00
cooling capacity nominal 42000 Btu/H
eer2 hsvtc 11.7
energy star certified No
seer 2 hsvtc 14.3
produced in us Yes
cooling operation range std max 125 °F
cooling operation range std min 55 °F
rated cooling condition ambient db 95 °F
rated cooling condition ambient wb 75 °F
max overcurrent protection 30 A
min circuit amps 18.95 A
power frequency 60 Hz
power phase 1 Ph
power voltage 208/240 V
rated load amps 14.4 A
compressor stages Single Stage
dimensions unit depth 35.5 in
dimensions unit height 35.75 in
dimensions unit width 35-1/2 in
sound pressure high cooling 72 dBA
weight unit 72 lb
cooling capacity rated 40000 Btu/H
additional refrigerant charge oz ft 0.64 lb
factory std refrigerant charge 82.6 oz
pipe size gas 7/8 in
pipe size liquid 3/8 in
refrigerant pre charged line length 15 ft
refrigerant type R-32
standard line set length max 200 ft
standard line set length vertical 79 ft
valve size suction o d 7/8 in
proposition 65 label Yes
carton type CTN
case qty 1
dimensions case depth 37.00 in
dimensions case height 38.50 in
dimensions case width 37.00 in
dimensions distribution unit depth 37 in
dimensions distribution unit height 38.5 in
dimensions distribution unit width 37 in
dimensions pallet depth 37.00 in
dimensions pallet height 38.50 in
dimensions pallet width 37.00 in
dimensions shipping unit depth 37.00 in
dimensions shipping unit height 38.50 in
dimensions shipping unit width 37.00 in
distribution shipping volume unit 52706.5 in³
shipping volume unit 52706.500 in³
truck factor 0.0000
volume case 52706.500 in³
volume distribution shipping unit 52706.5 in³
weight case 247.000 lb
weight distribution shipping unit 247 lb
weight shipping unit 247.000 lb
registered parts warranty commercial ALL PARTS - 5 YEARS PARTS
registered parts warranty multi family ALL PARTS - 10 YEARS PARTS
registered parts warranty residential ALL PARTS - 10 YEARS PARTS
standard parts warranty commercial ALL PARTS - 5 YEARS PARTS
standard parts warranty multi family ALL PARTS - 5 YEARS PARTS
standard parts warranty residential ALL PARTS - 5 YEARS PARTS
