Universal Floor/Ceiling Indoor • R454B • 230V • Single/Multi-Zone Compatible
Cooper&Hunter 24K Universal Floor Ceiling Indoor — CH-RSH24MFC
Flexible install (ceiling-horizontal or wall-vertical) with Smart Kit app control for commercial and residential open spaces.
CLICK HERE TO CONTACT US FOR CUSTOM QUOTES AND QUESTIONS CLICK TO CALL US 1-800-543-8933 FOR ANY QUESTIONS
Overview
The Cooper&Hunter CH-RSH24MFC is a 24,000 BTU universal floor/ceiling indoor unit built around installation flexibility and modern controls. Using R454B refrigerant, it can be mounted horizontally from a ceiling or vertically on a wall—ideal for retail, offices, and wide-open rooms where a wall mount isn’t a fit. A built-in Smart Kit enables app-based control, while the included refrigerant and humidity sensors support stable indoor comfort. TU1 copper tubing contributes to durability and efficient heat transfer.
Highlights
24,000 BTU Class SEER2 20.4 EER2 12.0 R454B Ceiling or Wall Install Built-in Smart Kit (App) Humidity Sensor Refrigerant Sensor TU1 Copper Tubes
- Orientation flexibility: ceiling-suspended (horizontal) or wall-mounted (vertical).
- Better for open layouts: strong option for small businesses, retail stores, and larger rooms.
- Connected controls: built-in Smart Kit supports control via the C&H app.
- Comfort sensing: humidity + refrigerant sensors help maintain consistent performance.
- Built to last: TU1 copper tubing supports long-term reliability.
ModelCH-RSH24MFC
Voltage208–230V, 1Ph
Line Set1/4" (liq) / 1/2" (gas)
Drain1"
What's Included
- Indoor universal floor/ceiling unit: CH-RSH24MFC
- Built-in Smart Kit (C&H app control)
- Refrigerant sensor + humidity sensor
- Remote control support and wall thermostat support (as configured)
Indoor Specs
| Spec | Details |
|---|---|
| Model | CH-RSH24MFC |
| Rated V-Ph-Hz | 208/230, 1, 60 |
| SEER2 / EER2 | 20.4 / 12.0 |
| Minimum Circuit Ampacity (MCA) | 2.5 A |
| Max Fuse | 15 A |
| Indoor Air Flow | 735.8 / 706.3 / 606.3 / 453.2 CFM |
| Indoor Noise (H/M/L) | 49 / 45 / 34 dB(A) |
| Refrigerant Piping (Liquid / Gas) | 1/4" / 1/2" |
| Unit Dimensions (W×H×D) | 42.05 × 26.57 × 9.25 in |
| Unit Net / Gross Weight | 61.29 / 73.19 lb |
| Drain Pipe Diameter | 1" |
| Operation Range (Cooling) | 60–90 °F |
| Operation Range (Heating) | 32–86 °F |
| ESP Range | / |
Note: The raw spec block you provided includes Cooling/Heating Btu/h = 18,000 lines that conflict with the 24K product description. If you paste the corrected capacity lines (Cooling/Heating Btu/h), I can update the table to match exactly.
Documents & Downloads
Important
Professional installation is recommended. This is an indoor unit intended to be paired with a compatible outdoor system. Confirm electrical requirements (208–230V), line sizes (1/4" liquid, 1/2" gas), condensate routing (1" drain), and clearances for your chosen orientation (ceiling or wall) prior to installation.
FAQs
Can this be installed on the ceiling or on a wall?
Yes. Install horizontally from the ceiling or vertically on a wall.
Is app control included?
Yes. It includes a built-in Smart Kit for control via the C&H app.
What line sizes are required?
1/4" liquid and 1/2" gas.
Is this single-zone or multi-zone?
It supports single-zone setups and can be used in multi-zone configurations when paired with compatible outdoor equipment.
