Universal Floor/Ceiling (Light Commercial) + Hyper Outdoor • R454B • 208–230V
Cooper&Hunter 60,000 BTU Hyper Single Zone Universal Floor/Ceiling Minisplit Heat Pump System R454B 230V
Overview
This system pairs the CH-RSH60LCFC Universal Floor/Ceiling indoor unit (single-zone / light commercial) with the CH-RHP60LCU-230VO Hyper outdoor unit. The indoor unit supports horizontal ceiling or vertical wall installation and uses R454B refrigerant with 3/8" liquid and 3/4" gas piping. The Hyper outdoor unit is built for cold-climate heating operation, with a heating ambient range listed down to -22°F.
Highlights
R454B Refrigerant Ceiling or Wall Install Light Commercial Ready Hyper Heating to -22°F Inverter Outdoor Control 3/8" / 3/4" Line Set AHRI: 205287344
- Flexible installation options: ceiling-suspended or wall-mounted orientation.
- Long-reach installation support (up to 246 ft max line length and 98.4 ft max height difference listed).
- Hyper outdoor heating range supports operation in extreme cold climates.
System Search
Line Set Size
3/8" Liquid • 3/4" Gas
Max Line / Lift
246 ft • 98.4 ft
Voltage
208–230V (187–253V)
Outdoor SEER2
18
Outdoor MCA / Max Fuse
44A • 45A
What’s Included
- Universal floor/ceiling indoor unit: CH-RSH60LCFC
- Hyper outdoor condenser: CH-RHP60LCU-230VO
- Remote control + wall thermostat support
- Built-in smart kit capability for app control (setup required)
Indoor Specs (CH-RSH60LCFC)
| Spec | Value |
|---|---|
| Rated V-Ph-Hz | 208/230, 1, 60 |
| Cooling / Heating | 54,000 / 60,000 BTU/h |
| MCA / Max Fuse | 3A / 15A |
| Indoor Air Flow (Turbo/Hi/Mi/Lo/Si) | 1365.6 / 1236.1 / 1083.0 / 892.8 / 777.0 CFM |
| Indoor Noise (Hi/Mi/Lo/Si) | 54.5 / 49.4 / 41.5 / 38.5 dB(A) |
| Dimensions (W×D×H) | 64.9 × 26.5 × 7.9 in |
| Packing (W×D×H) | 67.9 × 29.7 × 12.5 in |
| Net / Gross Weight | 95.24 / 111.33 lb |
| Operating Range | Cooling: 60–90°F • Heating: 32–86°F |
| Refrigerant Piping | 3/8" Liquid • 3/4" Gas |
Outdoor Specs (CH-RHP60LCU-230VO)
| Spec | Value |
|---|---|
| Refrigerant Type | R454B |
| Rated BTU | 60,000 |
| SEER2 / EER2 | 15.8 / 10.2 |
| Cooling Capacity (Min/Max) | 55,000 (14,200–60,000) BTU/h |
| Heating Capacity (Min/Max) | 60,000 (11,200–66,000) BTU/h |
| HSPF2 (Region V / IV) | 8.7 / 10.4 |
| Ambient Temperature | Cooling: -22–122°F • Heating: -22–75°F |
| Max Pipe Length / Height Difference | 246 ft / 98.4 ft |
| Voltage Range | 187–253V |
| Dehumidification | 7.67 pints/day |
| Dimensions (W×H×D) | 37.48 × 16.34 × 52.48 in |
| Net / Gross Weight | 230.38 / 261.69 lb |
| MCA / Max Fuse | 44A / 45A |
| Outdoor Noise | 63 dB |
| AHRI | 205287344 |
Documents & Downloads
- System Submittal (This Combination): CH-RHP60LCU-230VO + CH-RSH60LCFC
- Indoor Manuals
- Installation Manual
- UFC Leaflet (R454B)
- Owners Manual
- Outdoor Manuals
- UFC Leaflet (R454B)
- Outdoor Submittals (CH-RHP60LCU-230VO)
- CH-RHP60LCU-230VO + CH-RS60LCDT-HS
- CH-RHP60LCU-230VO + CH-RS60LCAHU
Important
- Line set size for this pairing: 3/8" liquid and 3/4" suction (gas).
- Confirm circuit sizing and overcurrent protection per outdoor MCA and local code requirements.
- Support: hvacsupplies.com/pages/contact • (800) 543-8933
FAQs
Can the indoor unit be installed on the ceiling or wall?
Yes. The CH-RSH60LCFC supports ceiling (horizontal) or wall (vertical) installation.
How cold can this Hyper system heat?
The Hyper outdoor unit’s heating ambient range is listed down to -22°F.
What line set size does this 60K LC floor/ceiling system use?
This pairing uses a 3/8" liquid line and a 3/4" gas (suction) line.
