Cooper&Hunter Olivia • R410A • Inverter • 115V
Cooper&Hunter 6,000 BTU Olivia Single Zone Wall Mount Minisplit Heat Pump System R410A 115V
SKU: CH-06OLVWM-115VI + CH-ES06-115VO
CLICK HERE TO CONTACT US FOR CUSTOM QUOTES AND QUESTIONS CLICK TO CALL US 800-543-8933 FOR ANY QUESTIONS
Overview
Get efficient, dependable comfort with this single-zone Cooper&Hunter Olivia wall-mount mini split heat pump bundle. It pairs a 6,000 BTU indoor unit with a matching 115V outdoor condenser using R410A refrigerant. Designed for precise temperature control and quiet operation, it’s a solid fit for smaller rooms, additions, offices, or other compact spaces.
Comfort features include multiple fan speeds, sleep mode, timer functions, and auto-swing louvers for better airflow distribution. Operation is simple with the included remote control.
Installation Kits: not included unless selected on the Variant Options (No installation, 16ft, 25ft, 50ft).
Highlights
Single Zone system 6,000 BTU class R410A refrigerant Up to 23 SEER2 115V, 1Ph, 60Hz Inverter heat pump Remote control included Auto swing louvers
- Efficient performance: up to 23 SEER2 and 13.8 EER2.
- Wide outdoor operating range: cooling down to -13°F and heating down to -13°F.
- Compact 115V solution: ideal when 208–230V isn’t available.
- Standard line set sizing: 1/4" liquid and 1/2" gas.
IndoorCH-06OLVWM-115VI
OutdoorCH-ES06-115VO
Lines1/4" liquid · 1/2" gas
Max run82.02 ft
What’s Included
- Indoor unit: CH-06OLVWM-115VI
- Outdoor unit: CH-ES06-115VO (Single Zone)
- Remote control (included)
- Manufacturer documentation (see Documents & Downloads)
Installation Kits: not included unless selected on the Variant Options (No installation, 16ft, 25ft, 50ft).
Indoor Specs
| Spec | Details |
|---|---|
| Model | CH-06OLVWM-115VI |
| System type | Single Zone |
| Refrigerant type | R410A |
| BTU rated | 6,000 |
| Power source | 115V, 1Ph, 60Hz |
| Voltage range | 103.5–126.5 V |
| SEER2 | 23 |
| EER2 | 13.8 |
| Dehumidification | 1.71 pnt/day |
| Refrigerant piping (liq/gas) | 1/4" / 1/2" |
| Minimum circuit ampacity | 3 |
| Max fuse | 15 |
| Indoor noise level (H/M/L) | 41.5 / 36 / 24 dB(A) |
| Indoor air flow | 341.18 / 300.00 / 241.18 / 176.47 |
| Drain pipe diameter | 5/8" |
| Unit dimensions (W×H×D) | 31.57 × 7.87 × 11.61 in |
| Net / Gross weight | 18.96 / 24.47 lb |
| Packing dimensions (W×D×H) | 34.45 × 11.22 × 14.96 in |
| Operating range (Cooling) | 60–90°F |
| Operating range (Heating) | 32–86°F |
| Controller | RG10K-exclusive remote |
Outdoor Specs
| Spec | Details |
|---|---|
| Model | CH-ES06-115VO |
| System type | Single Zone |
| Refrigerant type | R410A |
| BTU rated | 6,000 |
| Power source | 115V, 1Ph, 60Hz |
| Voltage range | 103.5–126.5 V |
| Max pipe length | 82.02 ft |
| Max height difference (IDU↔ODU) | 32.81 ft |
| Refrigerant piping (liq/gas) | 1/4" / 1/2" |
| Cooling capacity (Min/Max) | 6,000 (3,930–13,200) BTU/h |
| Heating capacity (Min/Max) | 7,000 (5,000–12,600) BTU/h |
| HSPF2-5 | 7.6 |
| HSPF2-4 | 9.8 |
| COP | 3.91 |
| Outdoor noise level | 54 dB(A) |
| Outdoor air flow | 794.12 |
| Minimum circuit ampacity | 19 |
| Max fuse | 25 |
| Ambient temp (Heating) | -13–75°F |
| Ambient temp (Cooling) | -13–122°F |
| Unit dimensions (W×H×D) | 30.12 × 11.93 × 21.85 in |
| Net / Gross weight | 66.80 / 72.31 lb |
| Packing dimensions (W×D×H) | 34.92 × 13.27 × 24.02 in |
| Refrigerant precharge | 25 |
| Additional charge (1/4" liquid) | 0.16 |
Documents & Downloads
Videos
Mini-split installation videos
Products overview
Important
This bundle is a single-zone system. Professional installation is recommended. Confirm electrical requirements, line sizes, maximum line length, and ambient operating limits before installation.
Installation Kits: not included unless selected on the Variant Options (No installation, 16ft, 25ft, 50ft).
FAQs
Is this system single-zone?
Yes — this bundle is configured as a single-zone system.
Are installation kits included?
Not included unless selected on the Variant Options: No installation, 16ft, 25ft, 50ft.
What line sizes does this system use?
1/4" liquid and 1/2" gas.
What is the max line length and height difference?
Maximum line length is 82.02 ft and maximum height difference is 32.81 ft.
What is the outdoor heating and cooling ambient range?
Cooling: -13–122°F. Heating: -13–75°F.
