Cooper&Hunter

Cooper&Hunter 18,000 BTU Single Zone Universal Floor/Ceiling Minisplit Heat Pump System R454B 230V

SKU: CH-RSH18MFC + CH-RES18-230VO

System highlights
AC Type
Universal Floor/Ceiling
Refrigerant Type
R454B
Brand
Cooper&Hunter
Outdoor Unit
18000 BTU VO (1.5 TON)
Indoor Unit
18000 BTU (1.5 TON)
Voltage
208-230V
Looking For
Universal Floor/Ceiling
Cooling Area (sq.ft.)
550-1000
SEER2 Rating
22.3
Line Set Length
$2,209.00 USD
$2,209.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details

Universal Floor/Ceiling + Regular Outdoor • R454B • 208–230V

Cooper&Hunter 18,000 BTU Single Zone Universal Floor/Ceiling Minisplit Heat Pump System R454B 230V

Overview

This system pairs the CH-RSH18MFC Universal Floor/Ceiling indoor unit with the CH-RES18-230VO Regular single-zone outdoor unit. The indoor unit supports horizontal ceiling or vertical wall installation for layout flexibility, plus built-in smart control capability, humidity sensing, and refrigerant sensing. The Regular outdoor unit delivers efficient inverter heating and cooling with heating ambient operation listed to -13°F.

Highlights

R454B Refrigerant Floor or Ceiling Install Inverter Comfort Control Humidity + Refrigerant Sensors Smart Kit + Remote + Wall Thermostat 1/4" / 1/2" Line Set Up to 22.3 SEER2 (Indoor)
  • Universal mounting options: ceiling-suspended or wall-mounted orientation to fit the space.
  • Smart control support via built-in smart kit and app connectivity (setup required).
  • Efficient inverter outdoor operation for stable temperatures and day-to-day savings.

System Search

CH-RSH18MFC + CH-RES18-230VO

Line Set Size

1/4" Liquid • 1/2" Gas

Max Line Length

98.4 ft

Voltage

208–230V (187–253V)

Outdoor Rated BTU

18,000

Outdoor AHRI

207742320

What’s Included

  • Universal floor/ceiling indoor unit: CH-RSH18MFC
  • Regular outdoor condenser: CH-RES18-230VO
  • Included remote control + wall thermostat support
  • Built-in smart kit capability for app control (setup required)

Indoor Specs (CH-RSH18MFC)

Spec Value
Rated V-Ph-Hz 208/230 • 1 • 60
Cooling / Heating 18,000 / 18,000 BTU/h
Minimum Circuit Ampacity (MCA) 1.9A
Max Fuse 15A
Indoor Air Flow (Turbo/Hi/Mi/Lo) 576.6 / 574.5 / 485.6 / 428.0 CFM
Noise (Hi/Mi/Lo/Si) 43.0 / 40.0 / 32.0 / 29.0 dB(A)
Dimensions (W×D×H) 42.0 × 26.5 × 7.9 in
Packing (W×D×H) 45.0 × 29.7 × 12.5 in
Net / Gross Weight 58.42 / 70.55 lb
Operating Range Cooling: 60–90°F • Heating: 32–86°F
Line Set 1/4" Liquid • 1/2" Gas

Outdoor Specs (CH-RES18-230VO)

Spec Value
Refrigerant Type R454B
Rated BTU 18,000
SEER2 / EER2 20 / 12.5
Cooling Capacity (Min/Max) 17,000 (7,000–19,000) BTU/h
Heating Capacity (Min/Max) 20,000 (5,500–22,000) BTU/h
HSPF2 (Region V / IV) 8.2 / 10.5
Ambient Temperature Cooling: -13–122°F • Heating: -13–75°F
Max Pipe Length / Height Difference 98.4 ft / 65.6 ft
Dimensions (W×D×H) 35.04 × 13.46 × 26.5 in
Net / Gross Weight 92.59 / 100.31 lb
MCA / Max Fuse 18A / 20A
AHRI 207742320

Documents & Downloads

Important

FAQs

Can the indoor unit be installed on the ceiling or wall?

Yes. The CH-RSH18MFC supports ceiling (horizontal) or wall (vertical) installation.

How cold can this Regular system heat?

The outdoor unit’s heating ambient range is listed to -13°F.

What control options are supported?

Smart kit/app capability (setup required), included remote control, and wall thermostat support.
