Cooper&Hunter 18,000 BTU Single Zone Floor Console Minisplit Heat Pump System R454B 230V

SKU: CH-RSH16MMC + CH-RES18-230VO

System highlights
AC Type
Mini Floor Console
Refrigerant Type
R454B
Brand
Cooper&Hunter
Outdoor Unit
18000 BTU VO (1.5 TON)
Indoor Unit
18000 BTU (1.5 TON)
Voltage
208-230V
Looking For
Mini Floor Console
Cooling Area (sq.ft.)
550-1000
SEER2 Rating
23.8
Line Set Length

NOTE: THE DEFAULT SELECTION DOES NOT INCLUDE AN INSTALLATION KIT. UPGRADE YOUR SELECTION TO ADD TO YOUR ORDER.

Price

$2,064.00
Shipping calculated at checkout.
View full details

Mini Floor Console + Hyper Outdoor • R454B • 208–230V

Cooper&Hunter 18,000 BTU Hyper Single Zone Floor Console Minisplit Heat Pump System R454B 230V

Overview

This system pairs the CH-RSH16MMC Mini Floor Console indoor unit with the CH-RHP18-230VO Hyper single-zone outdoor unit. The indoor console is designed for versatile comfort delivery with enhanced airflow outlets, plus humidity and refrigerant sensors. The Hyper outdoor unit adds cold-climate heating performance with heating ambient operation listed down to -22°F.

Highlights

R454B Refrigerant Hyper Heating to -22°F Humidity + Refrigerant Sensors Smart Kit + Remote + Wall Thermostat 1/4" / 1/2" Line Set Up to 20.0 SEER2 (Indoor)
  • Floor console form factor for flexible placement and room comfort delivery.
  • Enhanced airflow outlets designed for more even temperature distribution.
  • Inverter-driven outdoor operation for stable temperatures and efficient performance.

System Search

CH-RSH16MMC + CH-RHP18-230VO

Line Set Size

1/4" Liquid • 1/2" Gas

Max Line Length

98.4 ft

Voltage

208–230V (187–253V)

Outdoor Rated BTU

18,000

Outdoor AHRI

207742320

What’s Included

  • Indoor mini floor console: CH-RSH16MMC
  • Outdoor condenser (Hyper): CH-RHP18-230VO
  • Included remote control + wall thermostat support
  • Built-in smart kit capability for app control (setup required)

Video title (not linked): Multi-Zone System with R454B

Indoor Specs (CH-RSH16MMC)

Spec Value
Refrigerant Type R454B
BTU Rated 16K
SEER2 / EER2 20.0 / 12.5
Power 208–230V • 1Ph • 60Hz (187–253V)
Dehumidification 4.61 pints/day
Indoor Airflow 500.3 / 441.4 / 382.6 / 323.7
Noise (H/M/L) 43.5 / 40.5 / 30.5
Dimensions (W×D×H) 31.26 × 7.87 × 24.45 in
Net / Gross Weight 32.85 / 41.89
Line Set 1/4" Liquid • 1/2" Gas
Drain Pipe Diameter 5/8"
Operating Range Cooling: 60–90°F • Heating: 32–86°F
MCA / Max Fuse 3A / 15A
Packing (W×D×H) 34.06 × 11.02 × 28.31 in
Controller Remote controller

Outdoor Specs (CH-RHP18-230VO)

Spec Value
Refrigerant Type R454B
Rated BTU 18,000
SEER2 / EER2 18 / 12
Cooling Capacity (Min/Max) 17,000 (6,500–18,800) BTU/h
Heating Capacity (Min/Max) 19,000 (8,900–22,000) BTU/h
HSPF2 (Region V / IV) 9 / 10.5
COP 3.37
Ambient Temperature Cooling: -22–122°F • Heating: -22–75°F
Max Pipe Length / Height Difference 98.4 ft / 65.6 ft
Outdoor Air Flow 1,765.8
Noise 59
Dimensions (W×D×H) 35.04 × 13.46 × 26.50 in
Net / Gross Weight 99.87 / 107.80
MCA / Max Fuse 19A / 20A
Additional Charge (1/4" liquid) 0.16
AHRI 207742320

Documents & Downloads

Important

FAQs

What line set size is required?

1/4" liquid and 1/2" suction (gas).

How cold can this Hyper system heat?

The outdoor unit’s heating ambient range is listed to -22°F.

What control options are supported?

Remote control, wall thermostat support, and smart kit/app capability (setup required).
