Condenser Motor, 1/6 Hp, 230 V

SKU: FSE1018SF

System highlights
AC Type
Parts
Looking For
Condenser Fan Motors

Price

$252.99
Shipping calculated at checkout.

All brand names and model numbers are used for compatibility reference only. HVACSupplies.com is not affiliated with, endorsed by, or authorized by select manufacturers.

Compatibility is based on available technical data and is not guaranteed. HVAC equipment specifications may change. Customers are responsible for verifying compatibility with a licensed HVAC technician or the manufacturer prior to purchase, including confirmation with the specific model and serial number.

All part sales are final.
View full details
HVAC Replacement Part | Misc Motors | SKU FSE1018SF
Condenser Motor, 1/6 Hp, 230 V

Product Description

The Condenser Motor, 1/6 Hp, 230 V is an HVAC replacement motor. It is used for misc motors service and replacement work. Key details include Condenser Motor, PSC, Frame 48, 1/6 Hp, 230 V, 1 Ph, 50/60 Hz, 8P, Class F, 1.1 A, Sleeve Bearing, Direct Drive, TEAO, Stud Mount, 825 rpm, 0.5 in x 6.5 in Shaft, 5.6 in Dia x 11.49 in Lg.

Order by part number FSE1018SF and compare it with the label on your existing component before purchasing.

Technical Specifications - FSE1018SF

Part Number FSE1018SF
Full SKU MHVC-RES-PMF-FSE1018SF
Part Type Misc Motors
Category Motors and Fans
Catalog Detail Condenser Motor, PSC, Frame 48, 1/6 Hp, 230 V, 1 Ph, 50/60 Hz, 8P, Class F, 1.1 A, Sleeve Bearing, Direct Drive, TEAO, Stud Mount, 825 rpm, 0.5 in x 6.5 in Shaft, 5.6 in Dia x 11.49 in Lg
Power Phase 1 Ph
Power Voltage 230 V
Motor Speed Type PSC
