• Condenser Motor, 1/5-1/3 Hp
1 1

Condenser Motor, 1/5-1/3 Hp

SKU: PP3469F

System highlights
AC Type
Parts
Looking For
Condenser Fan Motors

Price

$248.99
Shipping calculated at checkout.

All brand names and model numbers are used for compatibility reference only. HVACSupplies.com is not affiliated with, endorsed by, or authorized by select manufacturers.

Compatibility is based on available technical data and is not guaranteed. HVAC equipment specifications may change. Customers are responsible for verifying compatibility with a licensed HVAC technician or the manufacturer prior to purchase, including confirmation with the specific model and serial number.

All part sales are final.
View full details
PROPARTS | Condenser Motors | SKU PP3469F
Condenser Motor, 1/5-1/3 Hp

Product Description

The PROPARTS Condenser Motor, 1/5-1/3 Hp is an HVAC replacement motor. It is used for condenser motors service and replacement work. Key details include 208-230 V, 1 Ph, 50/60 Hz, Class F, 1.2 A, Ball Bearing, Direct Drive, TEAO, 2 Speed, 825 rpm, 0.5 in x 6 in Shaft, 6.9 in Wd x 7.4 in Ht x 14.9 in Dp.

Order by part number PP3469F and compare it with the label on your existing component before purchasing.

Technical Specifications - PP3469F

Part Number PP3469F
Full SKU MHVC-RES-PMF-PP3469F
Brand PROPARTS
Part Type Condenser Motors
Category Motors and Fans
Catalog Detail 208-230 V, 1 Ph, 50/60 Hz, Class F, 1.2 A, Ball Bearing, Direct Drive, TEAO, 2 Speed, 825 rpm, 0.5 in x 6 in Shaft, 6.9 in Wd x 7.4 in Ht x 14.9 in Dp
Country of Origin India
Unit Height 7.4 in
Unit Width 6.90625 in
Unit Depth 14.9 in
Power Phase 1 Ph
Power Voltage 208-230 V
Unit Weight 19.25 lb
