HVAC Replacement Part | Condenser Motors | SKU 20462301S
Condenser Motor, 1/4 Hp, 1 Ph
Product Description
The Condenser Motor, 1/4 Hp, 1 Ph is an HVAC replacement motor. It is used for condenser motors service and replacement work. Key details include Condenser Motor, PSC, 1/4 Hp, 208/230 V, 1 Ph, 60 Hz, Class B, 1.1 A, Sleeve Bearing, Direct Drive, Clockwise, 1 Speed, 850 rpm, 0.45 in x 1.3 in Shaft, 5.61 in Dia x 7.05 in Lg.
Order by part number 20462301S and compare it with the label on your existing component before purchasing.
Technical Specifications - 20462301S
| Part Number | 20462301S |
|---|---|
| Full SKU | MHVC-RES-PMF-20462301S |
| Part Type | Condenser Motors |
| Category | Motors and Fans |
| Catalog Detail | Condenser Motor, PSC, 1/4 Hp, 208/230 V, 1 Ph, 60 Hz, Class B, 1.1 A, Sleeve Bearing, Direct Drive, Clockwise, 1 Speed, 850 rpm, 0.45 in x 1.3 in Shaft, 5.61 in Dia x 7.05 in Lg |
| Country of Origin | Mexico |
| Power Phase | 1 Ph |
| Power Voltage | 208/230 V |
| Motor Speed Type | PSC |
