HVAC Replacement Part | Belt Drive Blower Motors | SKU 0131L00070
Blower Motor, 3 Hp, 230 V, 3 Ph
Product Description
The Blower Motor, 3 Hp, 230 V, 3 Ph is an HVAC replacement motor. It is used for belt drive blower motors service and replacement work. Key details include Blower Motor, Frame 184 T, 3 Hp, 230 V, 3 Ph, 60 Hz, 4, 6P, Class F, 4.9 A, Ball Bearing, Belt Drive, Counter Clockwise, ODP, 1760 rpm, 1.13 in x 2.75 in Shaft, 8.75 in Wd x 14.69 in Lg x 8.5 in Ht.
Compatible model numbers are shown in the compatibility chart. Order by part number 0131L00070 and compare it with the label on your existing component before purchasing.
Technical Specifications - 0131L00070
| Part Number | 0131L00070 |
|---|---|
| Full SKU | MHVC-RES-PMF-0131L00070 |
| Part Type | Belt Drive Blower Motors |
| Category | Motors and Fans |
| Catalog Detail | Blower Motor, Frame 184 T, 3 Hp, 230 V, 3 Ph, 60 Hz, 4, 6P, Class F, 4.9 A, Ball Bearing, Belt Drive, Counter Clockwise, ODP, 1760 rpm, 1.13 in x 2.75 in Shaft, 8.75 in Wd x 14.69 in Lg x 8.5 in Ht |
| Country of Origin | Mexico |
| Unit Height | 8.5 in |
| Power Phase | 3 Ph |
| Power Voltage | 230 V |
| Unit Weight | 60 lb |
| Part Detail | Motor, 3 H.P., 3P |
Compatibility Chart
| Daikin | DCC150XXX3VXXX, DCC150XXX4VXXX, DCC150XXX7VXXX, DBC1504V000001S, DBC1507V000001S, DBC1503V000001S, DCG1502103VXXX, DCG1502104VXXX, DCG1502107VXXX, DBG1503VH00001S, DBG1504VH00001S, DBG1507VH00001S DBH1503V000001S, DBH1504V000001S, DBH1507V000001S |
|---|
